Machine Name –Dugard XP
Machine Model –XP 1000 S.N PV10180957 Y.O.M 2018
Descriptions –Fanuc Control 0iMF
X axis travel =1050 mm
Y axis travel = 540 mm
Z axis travel =560mm
XYZ Rapid traverse =44/44/25m/min
Table size = 1200mm x 480mm
12,000 Rpm spindle
Max load capacity on the table 1176kg
40 Spindle taper
36 station ATC
Coolant tank
TSC
Swarf conveyor
Machine Name –XYZ
Machine Model –1000 LR S.N SMD10120 Y.O.M 2022
Description –Siemens 828D
X axis travel = 1000mm
Y axis travel = 500mm
Z axis travel = 500mm
Table size=1060mm x 500mm
8000 rpm Spindle
7.5Kw spindle motor
Rapids 20m/min
24 station ATC
Work light
Coolant pump
Basic tool holder package

Machine Name –XYZ
Machine Model –1000 LR S.N SMD10120 Y.O.M 2018
Description –Siemens 828D
X axis travel = 1000mm
Y axis travel = 500mm
Z axis travel = 500mm
Table size=1060mm x 500mm
8000 rpm Spindle
7.5Kw spindle motor
Rapids 20m/min
20 station ATC
Work light
Coolant pump
Basic tool holder package

Machine Name –Yang
Machine Model –ML55A Y.O.M 1996
Description –Control Fanuc 0T
Chuck size 400mm
Faceplate 600mm
Swing 720mm
Between centres 120mm
Max.turning diameter 550mm
130 mm spindle bore
8 Station turret
Tailstock
Swarf conveyor
Renishaw tool setting probe
Manuals
Machine Name –Samsung
Machine Model –LCV 30XLB s.n l5b290267 Y.O.M 2015
Descriptions –Fanuc oi  Control
X axis travel =4000 mm
Y axis travel = 350 mm
Z axis travel =330mm
10,000 Rpm spindle
BT30 Spindle taper
16 station ATC
Renishaw toolsetter
Detron 4th axis
Coolant tank
Swarf conveyor
Machine Name –Churchill
Machine Model –BX /Servo cylindrical grinder S.N 10625 Retrofitted 2015
Description – 3048mm between centers
Table size 4500mm x 400mm
400mm swing
Fixed head
Filtration system
Machine weight 9000Kg

Machine Name –XYZ
Machine Model –DPM S.N 9296
Descriptions –Spindle Speeds 70-3600 rpm
Spindle Taper ISO 40
Table Size 1372 x 355 mm
X – Axis Travel 745mm
Y – Axis Travel 500mm
Z – Axis Travel 500mm
Quill Travel 127mm
Power Draw Bar
Coolant pump
Auto Lube System
Low Voltage work Lamp
Machine Name –XYZ
Machine Model –SMX 5000 (s.n 109070)
Descriptions –Prototrak 3 axis SMX control
X axis travel 1524mm
Y axis travel 596mm
Z axis travel 584mm
Table size 1930mm x 355mm
5000 rpm Spindle
7,5Kw spindle motor
Power drawbar
Work light
Coolant pump
Machine Name –XYZ
Machine Model –XYZ VM5000
Descriptions –Prototrak 3 axis SMX control
X axis travel 1524mm
Y axis travel 1596mm
Z axis travel 584mm
Table size 1930mm x 355mm
5000 rpm Spindle
7,5Kw spindle motor
Power drawbar
Work light
Coolant pump
Machine Name –XYZ
Machine Model –Sm3500 s.n 9763
Descriptions –YOM 2002
Pro track control Spindle Speeds 70-3600 rpm
Spindle Taper ISO 40
Table Size 1372 x 355 mm
X – Axis Travel 770mm Y – Axis Travel 500mm Z – Axis Travel 500mm Quill Travel 127mm
Power Draw Bar
Coolant pump
Auto Lube System
Low Voltage work Lamp
Work vice also supplied with machine
